PowerSonic PS-12180HD Lead Acid Battery

PowerSonic PS Series PS-12180HD 12 Volt / 18 Ah @20 Hr Lead Acid Battery with Recessed M5 Terminals / ABS Plastic Case

Out of stock

Loading...

Description

PowerSonic PS Series PS-12180HD 12 Volt / 18 Ah @20 Hr Lead Acid Battery with Recessed M5 Terminals / ABS Plastic Case

Specifications
Battery Store SKU PS-12180HDR
Dimensions 7.13″ (L) x 3.03″ (W) x 6.57″ (H)
Dimensions (mm) 181 mm (L) x 77 mm (W) x 167 mm (H)
Weight 13.354 lbs (6.07 kgs)

Additional information

Weight 6.0573346638846 lbs
Manufacturer

PowerSonic

Product Line
Product Series

PS Series

Model

PS-12180HD

Terminal

Recessed M5

Terminal Layout
Case Material

ABS Plastic

UPC Code
Manufacturers Model #

PS-12180HD

Manufacturers SKU
Deprecated Model #
Applications
Voltage

12

Capacity (Nominal)

18 Ah @20 Hr

Capacity @20 Hr

18.0

Capacity @10 Hr

16.7

Capacity @1 Hr

11.1

Capacity @15 Min

8.0

CCA
PHCA
Reserve Capacity
Chemistry

Lead Acid

Technology

VRLA-AGM

Design Life

5 Years

Service Life
Shelf Life

6

Internal Resistance

8.0 mOhm

Maximum Current

270

Cycles @ 80% Discharge
Standby Charge Voltage

13.5 to 13.8 VDC

Cycle Charge Voltage

14.1 to 14.7 VDC

Maximum Charge Current

0.25C

Operating Temp Low (°F)

-4

Operating Temp High (°F)

140

Storage Temp Low (°F)

5

Storage Temp High (°F)

122

Operating Temp Low (°C)

-20

Operating Temp High (°C)

60

Storage Temp Low (°C)

-15

Storage Temp High (°C)

50

Length (In)

7.13

Width (In)

3.03

Height - Case (In)

6.57

Height - Overall (In)

6.57

Length (mm)

181

Width (mm)

77

Height - Case (mm)

167

Height - Overall (mm)

167

Weight (lb)

13.354

Weight (kg)

6.07

BCI Group
Manufacturers Warranty
Transportation Notes
Certifications
Qty Per Box
Qty Per Pallet
