CSB GP1272F2FR (28W) SLA (AGM) Battery

CSB GP1272F2FR (28W) GP Series 12 Volt / 7.0 Ah @20 Hr with F2 (0.250″) Terminals and Flame Retardant UL94-V0 Case

This product is currently out of stock and unavailable.

Loading...

Description

CSB GP1272F2FR (28W) GP Series 12 Volt / 7.0 Ah @20 Hr with F2 (0.250″) Terminals and Flame Retardant UL94-V0 Case

Specifications
Battery Store SKU CS-GP1272-28WF2FR
Dimensions 5.94″ (L) x 2.56″ (W) x 3.70″ (H)
Dimensions (mm) 151 mm (L) x 65 mm (W) x 94 mm (H)
Weight 4.6 lbs (2.1 kgs)

Additional information

Weight 4.6 lbs
Manufacturer

CSB

price-discounts
Product Line
Product Series

GP Series

Model

GP1272-28W

Terminal

F2 (0.250")

Terminal Layout
Case Material

Flame Retardant UL94-V0

UPC Code
Manufacturers Model #

GP1272F2FR (28W)

Manufacturers SKU
Deprecated Model #
Applications
Voltage

12

Capacity (Nominal)

7.0 Ah @20 Hr

Capacity @20 Hr

7

Capacity @10 Hr
Capacity @1 Hr
Capacity @15 Min

28 W @15 Min

CCA
PHCA
Reserve Capacity
Chemistry

Lead Acid

Technology

AGM-Lead Calcium

Design Life
Service Life
Shelf Life

6

Internal Resistance
Maximum Current
Cycles @ 80% Discharge
Standby Charge Voltage

13.5 to 13.8 VDC

Cycle Charge Voltage

14.4 to 15.0 VDC

Maximum Charge Current
Operating Temp Low (°F)
Operating Temp High (°F)
Storage Temp Low (°F)
Storage Temp High (°F)
Operating Temp Low (°C)
Operating Temp High (°C)
Storage Temp Low (°C)
Storage Temp High (°C)
Length (In)

5.94

Width (In)

2.56

Height - Case (In)

3.70

Height - Overall (In)

3.90

Length (mm)

151

Width (mm)

65

Height - Case (mm)

94

Height - Overall (mm)

99

Weight (lb)

4.6

Weight (kg)

2.1

BCI Group

M7 Size

Manufacturers Warranty
Transportation Notes
Certifications
Qty Per Box
Qty Per Pallet
