PowerSonic PS-435ST Lead Acid Battery
PowerSonic PS Series PS-435ST 4 Volt / 3.5 Ah @20 Hr Lead Acid Battery with F1 (0.187″) Terminals / ABS Plastic Case
Loading...
Description
PowerSonic PS Series PS-435ST 4 Volt / 3.5 Ah @20 Hr Lead Acid Battery with F1 (0.187″) Terminals / ABS Plastic Case
| Specifications | |
|---|---|
| Battery Store SKU | PS-435STF1 |
| Dimensions | 3.54″ (L) x 1.34″ (W) x 2.32″ (H) |
| Dimensions (mm) | 90 mm (L) x 34 mm (W) x 59 mm (H) |
| Weight | 0.99 lbs (0.5 kgs) |
Additional information
| Weight | 1 lbs |
|---|---|
| Manufacturer | PowerSonic |
| Product Series | PS Series |
| Model | PS-435ST |
| Terminal | F1 (0.187") |
| Case Material | ABS Plastic |
| Manufacturers Model # | PS-435ST |
| Voltage | 4 |
| Capacity (Nominal) | 3.5 Ah @20 Hr |
| Capacity @20 Hr | 3.5 |
| Capacity @10 Hr | 3.26 |
| Capacity @1 Hr | 2.12 |
| Chemistry | Lead Acid |
| Technology | VRLA-AGM |
| Design Life | 5 Years |
| Shelf Life | 6 |
| Internal Resistance | 14 mOhm |
| Maximum Current | 35 |
| Standby Charge Voltage | 13.5 to 13.8 VDC |
| Cycle Charge Voltage | 14.1 to 14.7 VDC |
| Maximum Charge Current | 0.25C |
| Operating Temp Low (°F) | -4 |
| Operating Temp High (°F) | 140 |
| Storage Temp Low (°F) | 5 |
| Storage Temp High (°F) | 122 |
| Operating Temp Low (°C) | -20 |
| Operating Temp High (°C) | 60 |
| Storage Temp Low (°C) | -15 |
| Storage Temp High (°C) | 50 |
| Length (In) | 3.54 |
| Width (In) | 1.34 |
| Height - Case (In) | 2.32 |
| Height - Overall (In) | 2.32 |
| Length (mm) | 90 |
| Width (mm) | 34 |
| Height - Case (mm) | 59 |
| Height - Overall (mm) | 59 |
| Weight (lb) | 0.99 |
| Weight (kg) | 0.5 |
