PowerSonic PG-12V6 Lead Acid Battery

As low as $15.90 each

PowerSonic PG Series PG-12V6 12 Volt / 5.8 Ah @20 Hr Lead Acid Battery with F2 (0.250″) Terminals / ABS Plastic Case

Loading...

Description

PowerSonic PG Series PG-12V6 12 Volt / 5.8 Ah @20 Hr Lead Acid Battery with F2 (0.250″) Terminals / ABS Plastic Case

Specifications
Battery Store SKU PS-PG-12V6F2
Dimensions 3.54″ (L) x 2.75″ (W) x 3.97″ (H)
Dimensions (mm) 90 mm (L) x 70 mm (W) x 101 mm (H)
Weight 4.15 lbs (1.88 kgs)

Additional information

Weight 4.15 lbs
Manufacturer

PowerSonic

price-discounts

Each (1 pieces), Box/Case (10 pieces), Pallet Layer (100 pieces), Pallet (400 pieces)

Product Line
Product Series

PG Series

Model

PG-12V6

Terminal

F2 (0.250")

Terminal Layout
Case Material

ABS Plastic

UPC Code
Manufacturers Model #

PG-12V6

Manufacturers SKU
Deprecated Model #
Applications
Voltage

12

Capacity (Nominal)

5.8 Ah @20 Hr

Capacity @20 Hr

5.8

Capacity @10 Hr

5.58

Capacity @1 Hr

3.64

Capacity @15 Min
CCA
PHCA
Reserve Capacity
Chemistry

Lead Acid

Technology

VRLA-AGM

Design Life

12 Years

Service Life

Up to 12 Years

Shelf Life

6

Internal Resistance

45 mOhm

Maximum Current

50

Cycles @ 80% Discharge
Standby Charge Voltage

13.5 to 13.8 VDC

Cycle Charge Voltage

14.1 to 14.7 VDC

Maximum Charge Current

0.25C

Operating Temp Low (°F)

-4

Operating Temp High (°F)

140

Storage Temp Low (°F)

5

Storage Temp High (°F)

122

Operating Temp Low (°C)

-20

Operating Temp High (°C)

60

Storage Temp Low (°C)

-15

Storage Temp High (°C)

50

Length (In)

3.54

Width (In)

2.75

Height - Case (In)

3.97

Height - Overall (In)

4.21

Length (mm)

90

Width (mm)

70

Height - Case (mm)

101

Height - Overall (mm)

107

Weight (lb)

4.15

Weight (kg)

1.88

BCI Group
Manufacturers Warranty
Transportation Notes
Certifications
Qty Per Box
Qty Per Pallet
