PowerSonic DCG12-200 Lead Acid Battery

PowerSonic DCG Series DCG12-200 12 Volt / 200 Ah @20 Hr Lead Acid Battery with Recessed M8 Terminals / ABS Plastic Case

Out of stock

Loading...

Description

PowerSonic DCG Series DCG12-200 12 Volt / 200 Ah @20 Hr Lead Acid Battery with Recessed M8 Terminals / ABS Plastic Case

Specifications
Battery Store SKU PS-DCG12-200R
Dimensions 20.55″ (L) x 9.45″ (W) x 8.58″ (H)
Dimensions (mm) 522 mm (L) x 240 mm (W) x 218 mm (H)
Weight 138.7 lbs (62.9 kgs)

Product Notes

Superior cyclic life to AGM technology

Additional information

Weight 62.913907284768 lbs
Manufacturer

PowerSonic

Product Line
Product Series

DCG Series

Model

DCG12-200

Terminal

Recessed M8

Terminal Layout
Case Material

ABS Plastic

UPC Code
Manufacturers Model #

DCG12-200

Manufacturers SKU
Deprecated Model #
Applications
Voltage

12

Capacity (Nominal)

200 Ah @20 Hr

Capacity @20 Hr

200

Capacity @10 Hr

186

Capacity @1 Hr

110

Capacity @15 Min
CCA
PHCA
Reserve Capacity
Chemistry

Lead Acid

Technology

Gel

Design Life
Service Life
Shelf Life

12

Internal Resistance

3.4 mOhm

Maximum Current
Cycles @ 80% Discharge

600

Standby Charge Voltage

13.5 to 13.8 VDC

Cycle Charge Voltage

14.1 to 14.7 VDC

Maximum Charge Current

0.25C

Operating Temp Low (°F)

-4

Operating Temp High (°F)

140

Storage Temp Low (°F)

5

Storage Temp High (°F)

122

Operating Temp Low (°C)

-20

Operating Temp High (°C)

60

Storage Temp Low (°C)

-15

Storage Temp High (°C)

50

Length (In)

20.55

Width (In)

9.45

Height - Case (In)

8.58

Height - Overall (In)

8.82

Length (mm)

522

Width (mm)

240

Height - Case (mm)

218

Height - Overall (mm)

224

Weight (lb)

138.7

Weight (kg)

62.9

BCI Group
Manufacturers Warranty
Transportation Notes
Certifications
Qty Per Box
Qty Per Pallet
