Leoch LP12-80 SLA (AGM) Battery

Leoch LP Series LP12-80 12 Volt / 80 Ah @10 Hr Battery with Recessed M6 Terminals

This product is currently out of stock and unavailable.

Loading...

Description

Leoch LP Series LP12-80 12 Volt / 80 Ah @10 Hr Battery with Recessed M6 Terminals

Specifications
Battery Store SKU LE-LP12-80R
Dimensions 10.24″ (L) x 6.61″ (W) x 8.19″ (H)
Dimensions (mm) 260 mm (L) x 168 mm (W) x 208 mm (H)
Weight 52.4 lbs (23.8 kgs)

Additional information

Weight 52.4 lbs
Manufacturer

Leoch

price-discounts
Product Line
Product Series

LP Series

Model

LP12-80

Terminal

Recessed M6

Terminal Layout
Case Material

ABS Plastic

UPC Code
Manufacturers Model #

LP12-80

Manufacturers SKU

LP12-80

Deprecated Model #
Applications
Voltage

12

Capacity (Nominal)

80 Ah @10 Hr

Capacity @20 Hr

85.6

Capacity @10 Hr

80

Capacity @1 Hr

52

Capacity @15 Min
CCA
PHCA
Reserve Capacity
Chemistry

Lead Acid

Technology

AGM-Lead Calcium

Design Life

5 Years

Service Life

3-5 Years

Shelf Life

6 Months

Internal Resistance

6.2 mOhms

Maximum Current

800 Amps

Cycles @ 80% Discharge
Standby Charge Voltage

13.5-13.8 V @ 25C

Cycle Charge Voltage

14.4-15.0 V @ 25C

Maximum Charge Current

C/3

Operating Temp Low (°F)

5

Operating Temp High (°F)

122

Storage Temp Low (°F)

5

Storage Temp High (°F)

104

Operating Temp Low (°C)

-15

Operating Temp High (°C)

50

Storage Temp Low (°C)

-15

Storage Temp High (°C)

40

Length (In)

10.24

Width (In)

6.61

Height - Case (In)

8.19

Height - Overall (In)

8.43

Length (mm)

260

Width (mm)

168

Height - Case (mm)

208

Height - Overall (mm)

214

Weight (lb)

52.4

Weight (kg)

23.8

BCI Group
Manufacturers Warranty
Transportation Notes
Certifications
Qty Per Box
Qty Per Pallet
