EnerSys Genesis NP4.5-12FR Lead Acid (AGM) Battery

EnerSys Genesis NP Series NP4.5-12FR 12 Volt / 4.5 Ah @ 20 Hr with F1 (0.187″) Terminals

Loading...

Description

EnerSys Genesis NP Series NP4.5-12FR 12 Volt / 4.5 Ah @ 20 Hr with F1 (0.187″) Terminals

Specifications
Battery Store SKU EN-NP4.5-12F1FR
Dimensions 3.54″ (L) x 2.76″ (W) x 4.02″ (H)
Dimensions (mm) 90 mm (L) x 70 mm (W) x 102 mm (H)
Weight 3.74 lbs (1.7 kgs)

Product Notes

Discontinued by EnerSys, equivalents available

Additional information

Weight 3.74 lbs
Manufacturer

EnerSys

price-discounts

Each (1 pieces)

Product Line

Genesis

Product Series

NP Series

Model

NP4.5-12

Terminal

F1 (0.187")

Terminal Layout
Case Material

Flame Retardant ABS Plastic

UPC Code
Manufacturers Model #

NP4.5-12FR

Manufacturers SKU

NP4.5-12FR

Deprecated Model #
Applications

General Purpose

Voltage

12

Capacity (Nominal)

4.5 Ah @ 20 Hr

Capacity @20 Hr

4.5

Capacity @10 Hr
Capacity @1 Hr
Capacity @15 Min
CCA
PHCA
Reserve Capacity
Chemistry

Lead Acid

Technology

AGM

Design Life

3 Years

Service Life

3-5 Years

Shelf Life

6 Months

Internal Resistance
Maximum Current

6C

Cycles @ 80% Discharge

400

Standby Charge Voltage

13.5 to 13.8 Volts

Cycle Charge Voltage

14.4 to 15.0 Volts

Maximum Charge Current

C/10

Operating Temp Low (°F)

-5

Operating Temp High (°F)

122

Storage Temp Low (°F)

5

Storage Temp High (°F)

122

Operating Temp Low (°C)

-15

Operating Temp High (°C)

50

Storage Temp Low (°C)

-15

Storage Temp High (°C)

50

Length (In)

3.54

Width (In)

2.76

Height - Case (In)

4.02

Height - Overall (In)

4.25

Length (mm)

90

Width (mm)

70

Height - Case (mm)

102

Height - Overall (mm)

108

Weight (lb)

3.74

Weight (kg)

1.7

BCI Group
Manufacturers Warranty

12 Months

Transportation Notes
Certifications
Qty Per Box
Qty Per Pallet
uncategorized
