Qty 2 – EnerSys Genesis NP18-12B Lead Acid (AGM) Battery

$180.00

(Qty 2) EnerSys Genesis NP Series NP18-12B 12 Volt / 17.2 Ah @ 20 Hr with Nut & Bolt (M5) Terminals

51 in stock

Loading...

Description

(Qty 2) EnerSys Genesis NP Series NP18-12B 12 Volt / 17.2 Ah @ 20 Hr with Nut & Bolt (M5) Terminals

Specifications
Battery Store SKU EN-Q02V12A018
Dimensions 7.13″ (L) x 2.99″ (W) x 6.57″ (H)
Dimensions (mm) 181 mm (L) x 76 mm (W) x 167 mm (H)
Weight 13.574 lbs (6.17 kgs)

Additional information

Weight 13.574 lbs
Manufacturer

EnerSys

Product Line

Genesis

Product Series

NP Series

Model

NP18-12

Terminal

Nut & Bolt (M5)

Terminal Layout
Case Material

ABS Plastic

UPC Code
Manufacturers Model #

NP18-12B

Manufacturers SKU

NP18-12B

Deprecated Model #
Applications

General Purpose

Voltage

12

Capacity (Nominal)

17.2 Ah @ 20 Hr

Capacity @20 Hr

17.2

Capacity @10 Hr
Capacity @1 Hr
Capacity @15 Min
CCA
PHCA
Reserve Capacity
Chemistry

Lead Acid

Technology

AGM

Design Life

3 Years

Service Life

3-5 Years

Shelf Life

6 Months

Internal Resistance
Maximum Current

6C

Cycles @ 80% Discharge

400

Standby Charge Voltage

13.5 to 13.8 Volts

Cycle Charge Voltage

14.4 to 15.0 Volts

Maximum Charge Current

C/10

Operating Temp Low (°F)

-5

Operating Temp High (°F)

122

Storage Temp Low (°F)

5

Storage Temp High (°F)

122

Operating Temp Low (°C)

-15

Operating Temp High (°C)

50

Storage Temp Low (°C)

-15

Storage Temp High (°C)

50

Length (In)

7.13

Width (In)

2.99

Height - Case (In)

6.57

Height - Overall (In)

7.05

Length (mm)

181

Width (mm)

76

Height - Case (mm)

167

Height - Overall (mm)

179

Weight (lb)

13.574

Weight (kg)

6.17

BCI Group
Manufacturers Warranty

12 Months

Transportation Notes
Certifications
Qty Per Box

4

Qty Per Pallet

168

uncategorized
