CSB XTV12120-WT SLA (AGM) Battery

SKU: CS-XTV12120-WTF2FR Categories: , , , , , ,

CSB XTV12120-WT XTV Series 12 Volt / 12 Ah @20 Hr with F2 (0.250″) Terminals and Flame Retardant UL94-V0 Case

Loading...

Description

CSB XTV12120-WT XTV Series 12 Volt / 12 Ah @20 Hr with F2 (0.250″) Terminals and Flame Retardant UL94-V0 Case

Specifications
Battery Store SKU CS-XTV12120-WTF2FR
Dimensions 5.94″ (L) x 3.86″ (W) x 3.84″ (H)
Dimensions (mm) 151 mm (L) x 98 mm (W) x 98 mm (H)
Weight 9.1 lbs (4.2 kgs)

Additional information

Weight 9.1 lbs
Manufacturer

CSB

price-discounts

Each (1 Pieces)

Product Line
Product Series

XTV Series

Model

XTV12120-WT

Terminal

F2 (0.250")

Terminal Layout
Case Material

Flame Retardant UL94-V0

UPC Code
Manufacturers Model #

XTV12120-WT

Manufacturers SKU
Deprecated Model #
Applications
Voltage

12

Capacity (Nominal)

12 Ah @20 Hr

Capacity @20 Hr

12

Capacity @10 Hr
Capacity @1 Hr
Capacity @15 Min
CCA
PHCA
Reserve Capacity
Chemistry

Lead Acid

Technology

AGM-Gel

Design Life

12 Years

Service Life
Shelf Life

6

Internal Resistance

17.5 mOhm

Maximum Current

180 Amp

Cycles @ 80% Discharge
Standby Charge Voltage

13.5 to 13.8 VDC

Cycle Charge Voltage

14.4 to 15.0 VDC

Maximum Charge Current

3.6 Amp

Operating Temp Low (°F)

-4

Operating Temp High (°F)

122

Storage Temp Low (°F)

5

Storage Temp High (°F)

104

Operating Temp Low (°C)

-20

Operating Temp High (°C)

50

Storage Temp Low (°C)

-15

Storage Temp High (°C)

40

Length (In)

5.94

Width (In)

3.86

Height - Case (In)

3.84

Height - Overall (In)

4.01

Length (mm)

151

Width (mm)

98

Height - Case (mm)

98

Height - Overall (mm)

102

Weight (lb)

9.1

Weight (kg)

4.2

BCI Group
Manufacturers Warranty
Transportation Notes
Certifications
Qty Per Box
Qty Per Pallet
