FullRiver PV75255-EGLGC6YH SLA (AGM) Battery
FullRiver PV75255-EGLGC6YH Lead Acid PowerVault Series 24 Volt / 200 Ah @ 20 Hr with Plug – AMP Terminals and Flame Retardant ABS Plastic Case
Out of stock
Loading...
Description
FullRiver PV75255-EGLGC6YH Lead Acid PowerVault Series 24 Volt / 200 Ah @ 20 Hr with Plug – AMP Terminals and Flame Retardant ABS Plastic Case
| Specifications | |
|---|---|
| Battery Store SKU | FR-PV75255-EGLGC6YHCAFR |
| Dimensions | 25.50″ (L) x 7.50″ (W) x 25.58″ (H) |
| Dimensions (mm) | 648 mm (L) x 197 mm (W) x 650 mm (H) |
| Weight | 371.00 lbs (168.30 kgs) |
Additional information
| Weight | 371.00 lbs |
|---|---|
| Manufacturer | FullRiver |
| Product Line | Lead Acid |
| Product Series | PowerVault Series |
| Model | PV75255-EGLGC6YH |
| Terminal | Plug – AMP |
| Case Material | Flame Retardant ABS Plastic |
| Manufacturers Model # | PV75255-EGLGC6YH |
| Manufacturers SKU | PV75255-EGLGC6YH |
| Deprecated Model # | PV75255-EGLGC6YH |
| Applications | Material Handling |
| Voltage | 24 |
| Capacity (Nominal) | 200 Ah @ 20 Hr |
| Capacity @20 Hr | 200 |
| Chemistry | Lead Acid |
| Technology | AGM-Lead Calcium |
| Shelf Life | 6 |
| Maximum Current | 14.7 V |
| Cycles @ 80% Discharge | 800 |
| Standby Charge Voltage | 13.6 to 13.8 VDC |
| Cycle Charge Voltage | 14.4 to 14.7 VDC |
| Maximum Charge Current | 14.7 VDC |
| Operating Temp Low (°F) | 5 |
| Operating Temp High (°F) | 104 |
| Storage Temp Low (°F) | 5 |
| Storage Temp High (°F) | 122 |
| Operating Temp Low (°C) | -15 |
| Operating Temp High (°C) | 40 |
| Storage Temp Low (°C) | -15 |
| Storage Temp High (°C) | 50 |
| Length (In) | 25.50 |
| Width (In) | 7.50 |
| Height - Case (In) | 25.58 |
| Height - Overall (In) | 25.58 |
| Length (mm) | 648 |
| Width (mm) | 197 |
| Height - Case (mm) | 650 |
| Height - Overall (mm) | 650 |
| Weight (lb) | 371.00 |
| Weight (kg) | 168.30 |
| Manufacturers Warranty | 4 Year |
| Transportation Notes | 49 CFR Section 173.159(D) |
